Jilson Inch Radial Bearings
Jilson Inch Radial Bearings
SKU:BEA-70900d
Enhance performance with Jilson's Inch Radial Bearings, featuring non-magnetic, high-load capacity design for critical applications.
Regular price
$74.99
Regular price
Sale price
$74.99
Unit price
per
Initiate Order
Jilson Inch Radial Bearings
$74.99
Quantity: 1
Claim Your Seller Account
Jilson Inch Radial Bearings
$74.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your equipment with Jilson's high-quality plastic ball bearings and housings. Our R10A series bearings boast non-magnetic, corrosion-resistant properties, ideal for hospital and wash-down environments. Engineered from top-grade materials like Acetal and Glass, these bearings ensure durability and performance in challenging conditions. With a static load capacity of 48 lbs and dynamic capacity of 69 lbs, our bearings deliver reliability and efficiency. Trust Jilson for precision engineering and unmatched quality in every rotation.
Product Specifications
Specifications Balls
Glass
SPECIFICATIONS CAGE
Glass
Specifications Inside Diameter
5/8
Specifications Inside Diameter Range
5/8 in
Specifications Load Capacity Dynamic Lbs
69
Specifications Load Capacity Dynamic Lbs Range
61-80
Specifications Load Capacity Static Lbs
48
Specifications Load Capacity Static Lbs Range
41-60
Specifications Max Rpm In Air
1069
Specifications Notes
Jilson plastic ball bearings are well suited for other applications like wash down areas, where equipment is frequently wet and prone to rusting with conventional bearings. Corrosive environments, where bearings will be subject to chemical abrasiveness, a | We use top grade materials such as: Acetal, Nylon, Polypropylene, Polyethylene, KYNAR, PETP, PBT, PEEK, Ceramic and Stainless Steel in different combinations to meet specific needs. Jilsonâs housings for plastic bearings are made of high-grade, solid PBT
Specifications Outside Diameter
1-3/8
Specifications Outside Diameter Range
1-3/8 in
Specifications Races
Acetal
Specifications Rows
Single
Specifications Series
R10A
Specifications Width
3/8
