Jilson Inch Radial Bearings
Jilson Inch Radial Bearings
SKU:BEA-5e145a
Superior non-magnetic Jilson Inch Radial Bearings for sensitive applications. High-grade materials, high load capacities, and corrosion resistance.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Jilson Inch Radial Bearings
$59.99
Quantity: 1
Claim Your Seller Account
Jilson Inch Radial Bearings
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Jilson Inch Radial Bearings offer superior performance in corrosive environments and sensitive applications like hospitals. Made with top-grade materials such as Acetal, Nylon, and Glass balls for non-magnetic properties. With load capacities up to 69 lbs dynamic and 40.8 lbs static, plus a max RPM of 1069, these bearings ensure reliability and longevity.
Product Specifications
Specifications Balls
Glass
SPECIFICATIONS CAGE
PP
Specifications Inside Diameter
5/8
Specifications Inside Diameter Range
5/8 in
Specifications Load Capacity Dynamic Lbs
69
Specifications Load Capacity Dynamic Lbs Range
61-80
Specifications Load Capacity Static Lbs
40.8
Specifications Load Capacity Static Lbs Range
41-60
Specifications Max Rpm In Air
1069
Specifications Notes
Jilson plastic ball bearings are well suited for other applications like wash down areas, where equipment is frequently wet and prone to rusting with conventional bearings. Corrosive environments, where bearings will be subject to chemical abrasiveness, a | We use top grade materials such as: Acetal, Nylon, Polypropylene, Polyethylene, KYNAR, PETP, PBT, PEEK, Ceramic and Stainless Steel in different combinations to meet specific needs. Jilsonâs housings for plastic bearings are made of high-grade, solid PBT
Specifications Outside Diameter
1-3/8
Specifications Outside Diameter Range
1-3/8 in
Specifications Races
PP
Specifications Rows
Single
Specifications Series
R10
Specifications Width
9/32
