JIS 5K Steel Blind Flanges - Carbon Steel, 3" Size

Name: JIS 5K Steel Blind Flanges - Carbon Steel, 3" Size
Brand: World Wide Metric, Inc.
SKU: FLA-704e91
Price: 49.99 USD
Availability: OutOfStock

SKU:FLA-704e91

High-quality JIS 5K Steel Blind Flanges - Ideal for industrial use. Carbon steel, 3" size.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The JIS 5K Steel Blind Flanges are crafted from durable carbon steel, ensuring reliable performance in industrial settings. With a size of 3" and meeting JIS 5K pressure standards, these flanges feature precise dimensions of 180mm (D) and 145mm (C). Designed with 4 bolts for secure fitting, the flanges have a compact structure with a thickness of 14mm and a height of 19mm, weighing 2.70 kg. Ideal for sealing pipelines effectively, these blind flanges offer exceptional quality and compliance with industry standards.

Product Specifications

Specifications C

145 mm

Specifications D

180 mm

Specifications H

19 mm

Specifications Material

Carbon Steel

Specifications Number Of Bolts

Specifications Pressure

JIS 5K

Specifications Size

080 - 3"

Specifications T

14 mm

Specifications Weight

2.70 kg

JIS 5K Steel Blind Flanges - Carbon Steel, 3" Size
