KA50 Series Stepper Motor with D-Cut Double Shaft, 0.9 Degree/Step
KA50 Series Stepper Motor with D-Cut Double Shaft, 0.9 Degree/Step
SKU:STE-06eead
High torque, low vibration stepper motor with precise positioning for industrial applications.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
KA50 Series Stepper Motor with D-Cut Double Shaft, 0.9 Degree/Step
$79.99
Quantity: 1
Claim Your Seller Account
KA50 Series Stepper Motor with D-Cut Double Shaft, 0.9 Degree/Step
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The KA50 Series Stepper Motor with D-Cut Double Shaft combines high torque, low vibration, silent operation, and precise positioning for optimal performance. Employing the best magnetic balance in a round type design, this motor utilizes advanced technology for enhanced motor performance. With a NEMA 17 motor frame size, 0.9 deg./step angle, and robust design, it offers superior quality and reliability for a wide range of industrial applications.
Product Specifications
Additional Information 0
Explanation of Dynamic Torque Curves
Customize 0
Custom Designs
Dimensions 0
Outline | Outline
Specifications Current Per Phase
1.0 A
Specifications Detent Torque
2.5 oz·in | 18 mN·m
Specifications Holding Torque
65 oz·in | 458 mN·m
Specifications Inductance Per Phase
11.00 mH
Specifications L
1.97 in | 50 mm
Specifications Motor Frame Size
NEMA 17
Specifications Note
The basic motor characteristics, connection diagrams, and accessories (lead connectors) conform to the standard specifications.
Specifications Product Type
Stepper Motor
Specifications Reference Part Number
KA50KM1-552
Specifications Resistance Per Phase
5.10 Ω
Specifications Rotor Inertia
0.5 oz·in² | 100 g·cm²
Specifications Series
2 Phase Round KA
Specifications Shaft Specification
Double Shaft
Specifications Step Angle
0.9 deg./step
Specifications Type
KA Series Motors with D-Cut Double Shaft Motors (0.9 / 1.8 Degree/Step) - NEMA 17 / 23
Specifications Voltage Per Phase
5.10 V
Specifications Weight
420 g | 0.9 lb
Specifications Winding Method
Bipolar
Torque Curve 0
