KH56QM2-951 2 Phase Hybrid Square Stepping Motor
KH56QM2-951 2 Phase Hybrid Square Stepping Motor
SKU:STE-802439
Enhance your system with the KH56QM2-951 2 Phase Hybrid Square Stepping Motor for high-speed, precise motion control in a compact design.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
KH56QM2-951 2 Phase Hybrid Square Stepping Motor
$129.99
Quantity: 1
Claim Your Seller Account
KH56QM2-951 2 Phase Hybrid Square Stepping Motor
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The KH56QM2-951 2 Phase Hybrid Square Stepping Motor from our FWD Series is designed to deliver high performance, operating at speeds comparable to 5 phase motors. With a static torque of 1510 mN·m and advanced features like microstepping and out-of-step position detection, this motor ensures precise and efficient operation. It comes with a compact frame size of 56 x 56 mm, making it suitable for various applications requiring reliable torque output and smooth motion control.
Product Specifications
Additional Information 0
Allowable Radial Load and Allowable Thrust Load | Driver and Motor Selection Guide | Driver Picture | Explanation of Dynamic Torque Curves | Installation Location | KT Series, 3 phase Hybrid Stepping Motor (KT56QM1-551) | Stepping Servos FWD Series | System Configuration | Torque Stepping Drawing
Customize 0
Custom Designs
Dimensions 0
Connection Diagrams | External Drawing of the Driver | Wiring Diagram
Specifications Applicable Motor
KH56QM2-951
Specifications Basic Resolution
0.72 in
Specifications Current
2.0 A
Specifications Dielectric Strength Motor Section
500VAC 50Hz 1min
Specifications Driver Mass
0.51 lb
Specifications Excitation System
Basic Resolution (Step) | Micro Step (n=1, 2, 4, 8, 10, 20, 40, 80)
Specifications Insulation Class Motor Section
Equivalent to class
Specifications Insulation Resistance Motor Section
500VDC 100 MO min
Specifications Max Static Torque
1510 mN·m | 214 oz.in
Specifications Motor Frame Size
56 x 56 mm | 2.205 x 2.205 in
Specifications Motor Mass
2.03 lb
Specifications No Of Phases
2
Specifications Power Specifications
24VDC, 4.0A
Specifications Rotor Inertia
3.81 x 103 oz·in²
Specifications Storage Ambient Humidity Driver Section
35~85 %
Specifications Storage Ambient Humidity Motor Section
10~85 %
Specifications Storage Ambient Temperature Driver Section
0~+50 ºC
Specifications Storage Ambient Temperature Motor Section
-20~+70 ºC
Specifications Type
2 Phase Hybrid Square KH Series
Specifications Working Ambient Humidity Driver Section
0~+50 ºC
Specifications Working Ambient Humidity Motor Section
15~85 %
Specifications Working Ambient Temperature Driver Section
0~+50 ºC
Specifications Working Ambient Temperature Motor Section
-10~+50 ºC
Torque Curve 0
