Kumho ABS/CNT Composite - 1.05 SG, 20% Tensile Elongation
Kumho ABS/CNT Composite - 1.05 SG, 20% Tensile Elongation
SKU:ACR-f97d2a
Versatile Kumho ABS/CNT Composite - optimal for electronic parts, conductive coatings, and more. Superior strength and conductivity.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
Kumho ABS/CNT Composite - 1.05 SG, 20% Tensile Elongation
$34.99
Quantity: 1
Claim Your Seller Account
Kumho ABS/CNT Composite - 1.05 SG, 20% Tensile Elongation
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Kumho ABS/CNT Composite combines superior specific gravity and exceptional tensile elongation, making it ideal for a wide range of applications from electronic parts trays to conductive coatings. With compliance to ASTM standards, this composite offers increased adhesion, mechanical strength, and gloss quality. Benefit from outstanding electrical conductivity, thermal stability, and abrasion resistance, perfect for industries requiring high-performance materials. Kumho's CNT boasts highly oriented structures, preferred by major battery and tire manufacturers globally.
Product Specifications
Additional Information
The products coated in conductive solution have increased adhesion, mechanical strength and abrasion resistance.MAB150 is excellent in gloss and surface quality and MAB150M is outstanding in recognition rate of laser marking.Electro-conductivity is revealed by the addition of CNT to ABSEAB120 can be processed by the non-painting and increase painting efficiency with uniform conductivityCNT is known as having excellent electrical conductivity, thermal conductivity, strength, and thermal stability. Demand for Li-ion Battery as positive electrode conductive additives has been increasing and CNT is also being used in applications such as tire treads and antistatic resins.Kumho's CNT have a highly oriented bundle structure and have been used by major battery manufacturers and tire manufacturers globally. Multiple grades of CNT are available depending on required property and each application, and we also have various types of rubber and resin compound and masterbatches.Kumho Petrochemical with one of the world's largest synthetic rubber manufacturing capacities was established in 1970 and developing their business in several fields including synthetic resins, specialty chemicals, nanocarbons, energy, and building materials.Major application with Kumho's CNTLi-ion Battery as positive electrode conductive additives for automotiveTire treadsElectronic Parts TraysConductive coatingElectro-Magnetic Interference (EMI) Shielding CompositeConductive resin/rubber
Applications
Case | Technical Parts
Technical Specs Brands
Heidon
Properties Flexural Modulus 10 Millimeter Mm Per Minute
21,500 kgf/cm²
Properties Flexural Strength 10 Millimeter Mm Per Minute
680 kgf/cm²
Properties Heat Deflection Temperature 186 Kilogram Kgsq
87 ºC
Properties Izod Impact Notched 32 Millimeter Mm
18 kgf·cm/cm
Properties Melt Flow Index 200 Degree Celsius C Temperat
30 g/10min
Properties Rockwell Hardness R Scale
109
Properties Specific Gravity
1.05
Properties Tensile Elongation At Break 50 Millimeter Mm
20 %
Properties Tensile Strength 50 Millimeter Mm Per Minute
500 kgf/cm²
Properties Test Method For Flexural Modulus 10 Millimete
American Society for Testing and Materials (ASTM) D256
Properties Test Method For Flexural Strength 10 Millimet
American Society for Testing and Materials (ASTM) D790
Properties Test Method For Heat Deflection Temperature 1
American Society for Testing and Materials (ASTM) D648
Properties Test Method For Izod Impact Notched 32 Millim
American Society for Testing and Materials (ASTM) D256
Properties Test Method For Melt Flow Index 200 Degree Ce
American Society for Testing and Materials (ASTM) D1238
Properties Test Method For Rockwell Hardness R Scale
American Society for Testing and Materials (ASTM) D785
Properties Test Method For Specific Gravity
American Society for Testing and Materials (ASTM) D792
Properties Test Method For Surface Resistivity At 23 Deg
American Society for Testing and Materials (ASTM) D257
Properties Test Method For Tensile Elongation At Break 5
American Society for Testing and Materials (ASTM) D638
Properties Test Method For Tensile Strength 50 Millimete
American Society for Testing and Materials (ASTM) D638
