Large Compression Latch Cylinder, H Grip Range 25.4-41.1mm, Tubular Key Operated

Name: Large Compression Latch Cylinder, H Grip Range 25.4-41.1mm, Tubular Key Operated
Brand: All Electronics Hardware
SKU: IND-f3f861
Price: 45.99 USD
Availability: OutOfStock

SKU:IND-f3f861

Secure doors and flaps with our Tubular Key Operated Large Compression Latch. H Grip Range 25.4-41.1mm, reserved cam style, and IP65/NEMA 4 compliant.

$45.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Enhance security with our Large Compression Latch Cylinder designed for robust locking of doors and flaps. Featuring a reserved cam style, tubular key operation, and H grip range of 25.4 to 41.1mm, this latch ensures reliable protection. Crafted with durable materials including mild steel, die-cast zinc, and zinc-plated finishes, it offers IP65 and NEMA 4 compliance. Suitable for left and right-hand applications, this latch meets stringent industry standards for ingress protection and electrical enclosures.

Product Specifications

Specifications Cam Style

Reserved

Specifications Cylinder Type

Tubular Key Operated

Specifications H Grip Range

25.4 to 41.1 mm

Specifications Industry Standards

Ingress Protection (IP65) | National Electrical Manufacturers Association (NEMA 4)

Specifications Material

Cam: Mild Steel | Housing and Cylinder: Die-Cast Zinc

Specifications Special Features

Left | Right

Specifications Surface Finish

Cam: Zinc Plated | Housing and Cylinder: Black Powder Coated
