LaserCELL High Performance Fully Enclosed Carbon Dioxide (CO2) Laser Engraving and Cutting Systems
LaserCELL High Performance Fully Enclosed Carbon Dioxide (CO2) Laser Engraving and Cutting Systems
SKU:LAS-6362dc
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
LaserCELL High Performance Fully Enclosed Carbon Dioxide (CO2) Laser Engraving and Cutting Systems
$49.99
Quantity: 1
Claim Your Seller Account
LaserCELL High Performance Fully Enclosed Carbon Dioxide (CO2) Laser Engraving and Cutting Systems
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The LaserCELL's Class 2 safety enclosure allows the system to be placed in high-traffic areas, such as busy factory floors and university classrooms. Access points are available at the front, back and each side of the machine, making part loading and maintenance simple and convenient.Kern has redesigned the LaserCELL's motion system, transforming it into its fastest and most productive machine to date. An improved downdraft vacuum table is built into the system allowing for consistent fume removal and material hold down over the entire 52" x 50" table. Lasers from 100 to 650 watts can be placed onto the LaserCELL system. Capable of cutting and marking metals such as stainless steel, aluminum, mild steel and thin brass; and non-metals such as fabrics, plastics/acrylics, wood, stone, glass, rubber, printed materials, etc This machine can also be equipped with our Camera Vision System, Rotary, and/or our pen marking system.
Product Specifications
Additional Features
UL Electrical PanelA UL certified electrical panel is placed on each laser system which turns on and shuts down components of the laser system. CUL and CE approved machines are available by request.LED LightsUltra-bright LED Lights span the top of the enclosures interior, resulting in a well-lit processing work area. These lights make it easy to see the status of the current job being processed.Steel ChassisThe LaserCELL is built around a precision-machined, heavy-duty steel weldment as the machine base. The one-piece weldment allows for the machine to arrive fully assembled, greatly reducing installation time.Convenient AccessThe LaserCELL features sliding doors at the front and rear of the machine. Sliding side access doors are installed on both sides. These access points ensures convenient loading and unloading of materials.Honeycomb BedA durable aluminum table structure is inserted into the bed, maintaining a flat work surface. The honeycomb cells allow for a down draft table and also ducting smoke and debris into the bottom table chamber.2.5" S-focus Lens AssemblyA great all-around processing head equipped with a high-quality optic. The assembly features an assist air which pushes air out of the nozzle, protecting the lens from smoke and debris.
Additional Information
As the fastest and most productive system in Kern's product lineup, the LaserCELL is the perfect blend of safety and performance that companies are demanding from today’s laser processing equipment.Leading Manufacturer of State-of-the-art Laser Cutting.
Dimensions Compact Footprint Height
75 in
Dimensions Compact Footprint Length
85 in
Dimensions Compact Footprint Width
74 in
Dimensions Door Extended Footprint Height
77 in
Dimensions Door Extended Footprint Length
114 in
Dimensions Door Extended Footprint Width
115 in
Dimensions Footprint Height
53 in | 1346 mm
Dimensions Footprint Length
87 in | 2210 mm
Dimensions Footprint Width
74 in | 1880 mm
Dimensions Note For Compact Footprint
Doors closed and minor parts removed. Further reduction in footprint is possible with removal of complete enclosure.
Electrical Industry Standards For 3 Phase At 415 Volt V Voltage
European Conformity (CE)
Electrical Number Of Phase
1 | 3
Electrical Voltage At 1 Phase
230 V
Electrical Voltage At 3 Phase
230 V | 415 V | 480 V
Kcam Laser Software
KCAM® is a laser cutting and engraving software package developed by Kern's in-house software development team. Through years of research and customer feedback, KCAM® has developed into an industry-leading laser control software.KCAM® can be linked with popular design softwares such as CorelDRAW®, AutoCAD® and Adobe Illustrator®, allowing for hundreds of file types to be processed. A convenient user interface provides operators with complete control of the laser systems cutting and engraving parameters. Kern's customers have access to the latest KCAM® software upgrades from our website.Whether you’re cutting thick acrylic or a thin delicate textile, be ensured that KCAM® will provide you with the laser control required for quick and accurate results.File CompatibilityA macro within CorelDRAW® automatically sends your artwork to KCAM® with the click of a single button. KCAM® is also capable of directly opening common file types such as .dxf, .pdf, G-CODE and many more.Other popular CAD softwares such as AutoCAD LT®, Adobe Illustrator® and Solidworks® can be used to automatically load files into KCAM®.Gives You ControlCustomized Pierce Settings. The dwell time, laser power, frequency, focus point and air flow can be set independently from your normal cut settings. This feature ensures metals are cut clean with minimal to no dross.Air Control. Compressed shop air, oxygen or nitrogen can be hooked up to the laser system for optimal processing results on a variety of laserable materials.Vector Path Speed Control. KCAM® mimics a race car by slowing the cutting speed into sharp corners and accelerating out of them. The result is smooth, consistent cutting with the tap of your mouse.Saves You TimeCut Optimizer. Decrease your programming time by letting KCAM® automatically determine the fastest cut order for your most complicated designs.Time Estimator. Provide accurate pricing to your customers by knowing the amount of laser processing time before the product even makes it to the laser bed.Tool Offset. A simple inside/outside offset can be set to compensate for the laser beam kerf. This results in precisely sized parts without modification of your original part drawings.More KCAM® FeaturesBottom-Up & Top-Down EngravingVector Path Speed ControlSoft Home PositioningPart ArrayingAutomation PausesVision Registration SystemVariable Extents EngravingLead-In Speed ControlLine Color SortingPhotoGRAV CompatibleAnti-Banding Engraving ModeHistory LogNine Vector Cutting ColorsLaser Printer DriverTime EstimatorPower Density Control for CornersMultiple Modulation ModesSystem Usage Log
Materials Cut Material
Acrylic | Aluminum | Anodized Aluminum | Brass | Foam | Leather | Mild Steel | Stainless Steel | Wood
Materials Mark Material
Acrylic | Aluminum | Anodized Aluminum | Foam | Leather | Mild Steel | Stainless Steel | Stone | Wood
Specifications Air Assist Pressure
100 to 250 psi | 9 to 17 bar
Specifications Certification
Underwriters Laboratories (UL)
Specifications Laser Classification
Class 2 Carbon Dioxide (CO2) Laser
Specifications Laser Wattage
100 to 650 W
Specifications Maximum Cutting Speed
20 in/s
Specifications Maximum Engraving Speed
150 in/s
Specifications Optional Packages
Fume Extractor | K-Vision Camera | Metal Cutting | Pipe Rotary Attachment
Specifications Origin
Made in USA
Specifications Part Clearance
3 in | 76.2 mm
Specifications Positioning Accuracy
0.002 in/ft | 0.1670 mm/m
Specifications Repeatability
0.0005 in/ft | 0.0417 mm/m
Specifications System Weight
3700 lb
Specifications Vacuum Blower Air Flow
>1500 ft³
Specifications Work Area
52 x 50 in | 1320 x 1270 mm
Standard Features
Super Pulsed CO2 Laser100-650 watt CO2 lasers with super pulse technology, developed by kern Technologies, excels in cutting dense and highly reflective materials.Closed-loop ChillerA closed-loop chilling unit properly cools the laser source, ensuring a long laser lifetime and consistent cutting and engraving results.Vacuum & Fume ExhaustA blower package will remove fumes and small debris created during laser processing. An integrated downdraft table holds material flat on the table.Computer PackageA high-performance computer and monitor is included with each system. An adjustable monitor arm is installed at the front corner of the machine.Software PackageKCAM® Laser Software and CorelDRAW Graphics Suite are linked together allowing over 100 file types to be used, including .DXF, .PDF and G-CODE.Safety FeaturesA Class 2 enclosure with interlocked access points ensure a safe working environment. Multiple emergency stop buttons are installed on the machinery.Hyperdual MotionKern's next generation HyperDual motion package features a rack and pinion design driven by powerful servo motors at each side of the table.Training ProgramA 2 day training course at Kern's factory is included with each system. Kern's knowledgeable staff will cover safety, maintenance, operation and applications.
