Lead-Free Attenuation Blanket Shielding 3ft Length
Lead-Free Attenuation Blanket Shielding 3ft Length
SKU:BLA-d8700c
Innovative lead-free attenuation blanket shielding with 19% attenuation, NFPA 805 compliant for industrial radiation protection.
Regular price
$189.99
Regular price
Sale price
$189.99
Unit price
per
Initiate Order
Lead-Free Attenuation Blanket Shielding 3ft Length
$189.99
Quantity: 1
Claim Your Seller Account
Lead-Free Attenuation Blanket Shielding 3ft Length
$189.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience the innovation of our lead-free attenuation blanket shielding, a safe and effective solution for industrial radiation protection. Our proprietary blend of bismuth and iron powders offers 19% attenuation, equivalent to traditional lead products but at a lighter weight. With high chemical resistance and ruggedness, this blanket guarantees 20 years of service without settling or breaking. Cuttable and easy to handle, it surpasses industry standards like NFPA 805, ensuring superior performance and safety.
Product Specifications
Additional Information Additional Information
An alternative to lead blankets, similar attenuation characteristics without the lead hazard. Blankets can be cut in the field using a utility knife, but can stand up to normal wear and tear. Increased flexibility over a standard lead blanket allows for wrapping shielding closer to the source and easier handling characteristics.
Chemical Resistance Chemical Resistance
Highly resistant to exposure to Boric Acid and Sodium Hydroxide with virtually no change in physical properties after 168 hours of exposure. Excellent chemical resistance at elevated temperatures.
Dimensions Length
3 ft
Dimensions Width
1 ft
Leach Products Chlorine
10 ppm
Leach Products Fluorine
4 ppm
Leach Products Sulfur
180 ppm
Leach Products Total
14 ppm
Leach Products Zinc
125 ppm
Material Ruggedness Material Ruggedness
Highly resistant to physical abuse including puncture except material does cut with sharp scissors or other cutting devices. Very good abrasion and tear resistance
Note Note
Testing results as reported by Bridgeport Testing Laboratory, Inc. for ANO.
Specifications Attenuation
19 %
Specifications Density
10 lb/ft²
Specifications Industry Standards And Certifications
National Fire Protection Association (NFPA) 805
Specifications Material
Tungsten
Specifications Material Compatibility
Carbon Steel | Galvanized | Stainless Steel
Specifications Minimum Combustible Or Exempt Estimated Heat Cont
1364 Btu/lb
Specifications Operating Temperature
50 to 250 ºC
Specifications Weight
30 lb
