The Legris 3101 Male Stud Fittings are designed for seamless tubing-to-threaded port connections. Featuring a solid construction and compact design, these fittings ensure a secure and aesthetic connection. With external tightening options using a flat spanner or Allen key and internal adjustment capability, these fittings offer ease of installation and maintenance. Each unit undergoes rigorous quality control measures and is dated to ensure traceability. Meeting RoHS and ISO 14743 standards, these fittings guarantee reliable performance.
Product Specifications
Specifications C
M3x0,5
Specifications E
2.5 mm
Specifications F1
8 mm
Specifications H
12.5 H
Specifications Kg
0.003 kg
Specifications Od Mm
3 mm
Technical Specifications Body Material
Nickel Plated Brass
Technical Specifications Gripping Ring
Stainless Steel
Technical Specifications Maximum Working Pressure
20 bar | 2 MPa | 290 psi
Technical Specifications O Ring Material
NBR
Technical Specifications Vacuum Capability
755 mmHg
Technical Specifications Working Temperature
-20 to 80 ºC | -4 to 176 ºF | 253 to 353 ºK
