Legris 3101 Male Stud Fittings - Hexagonal, BSPP & Metric

Name: Legris 3101 Male Stud Fittings - Hexagonal, BSPP & Metric
Brand: Caylor Industrial Sales, Inc.
SKU: FIT-de98cc
Price: 24.99 USD
Availability: OutOfStock

SKU:FIT-de98cc

Efficient Male Stud Fittings for precise tubing connections. Compact, durable, and RoHS compliant.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Legris 3101 Male Stud Fittings offer seamless tubing-to-port connections with external tightening using a flat spanner or Allen key. Featuring solid construction, these fittings are compact, aesthetically pleasing, and provide optimal air flow. Each unit undergoes rigorous quality control and dating for traceability. Compliant with RoHS and ISO 14743 standards, ensuring reliability and performance.

Product Specifications

Specifications C

M5x0,8

Specifications E

3.5 mm

Specifications F1

8 mm

Specifications F2

2.5 mm

Specifications H

12.5 H

Specifications K

8.5

Specifications Kg

0.004 kg

Specifications Od Mm

3 mm

Technical Specifications Body Material

Nickel Plated Brass

Technical Specifications Gripping Ring

Stainless Steel

Technical Specifications Maximum Working Pressure

20 bar | 2 MPa | 290 psi

Technical Specifications O Ring Material

NBR

Technical Specifications Vacuum Capability

755 mmHg

Technical Specifications Working Temperature

-20 to 80 ÂºC | -4 to 176 ÂºF | 253 to 353 ÂºK
