Lewis 8-1/8 in. Ball Bearing Swivel for Rigging Applications
Lewis 8-1/8 in. Ball Bearing Swivel for Rigging Applications
SKU:PUL-89a970
Upgrade your rigging systems with the Lewis 8-1/8 in. Ball Bearing Swivel. Sealed for durability, with a 4000 lb working load capacity.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Lewis 8-1/8 in. Ball Bearing Swivel for Rigging Applications
$49.99
Quantity: 1
Claim Your Seller Account
Lewis 8-1/8 in. Ball Bearing Swivel for Rigging Applications
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your rigging operations with the Lewis 8-1/8 in. Ball Bearing Swivel. With a sealing to protect its internal components, this swivel boasts a maximum working load of 4000 lb and an ultimate tensile strength of 10000 lb. Designed for durability and efficiency, this swivel ensures smooth operation and safety in rigging applications. Always exceeding industry standards, Lewis products are meticulously inspected for quality and performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Body Diameter F
2 in
Dimensions Large Inner Diameter C
1-1/2 in
Dimensions Large Outer Diameter B
2-9/16 in
Dimensions Length A
8-1/8 in
Dimensions Small Inner Diameter E
1-1/4 in
Dimensions Small Outer Diameter D
2-5/16 in
Features
Sealed Ball Bearing Swivel for Rigging
Specifications Brand
Lewis
Specifications Type
Bearing Swivel
Specifications Ultimate Tensile Strength Uts
10000 lb
Specifications Work Load Wl
4000 lb
Warning
Read The Following Before Using Lewis Ball Bearing SwivelsIt is essential to inspect all Lewis swivels before and after each use. If the swivel is loose and/or the bearings feel rough when rotated or are seized and cannot be rotated, the swivel should be removed from service immediately.Always select a swivel larger than the machine capacity. If a Lewis swivel is exposed to a load exceeding the posted work load it should be removed from service immediately, and a larger swivel should thereafter be used.It is important that you read and understand all breaking strength, safety & technical data relating to all Lewis Manufacturing Company products. Please order carefully. Do not exceed published working load on any Lewis swivel.Lubricate all greasable swivels before and after each use.
