Liquid Tight Flexible Metal Conduit - Type EFST

Name: Liquid Tight Flexible Metal Conduit - Type EFST
Brand: Anamet Electrical, Inc.
SKU: LIQ-21fbc3
Price: 299.99 USD
Availability: OutOfStock

SKU:LIQ-21fbc3

Flexible, liquid-tight raceway conduit for superior wiring protection in various trade sizes. IP 67 rated with durable construction for General Construction Grade Applications.

$299.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Liquid Tight Flexible Metal Conduit - Type EFST is an essential solution for wiring applications that require a flexible, liquid-tight raceway. Constructed with a hot-dipped zinc galvanized steel core and a PVC outer jacket, this conduit ensures durability and reliability. Approved for IP 67 rating when used with designated end connectors, it offers superior wiring protection in a temperature range of -4ºF to +176ºF. Ideal for General Construction Grade Applications, it comes in various trade sizes from 1/4" to 6" to meet diverse needs.

Product Specifications

Application 0

Designed for General Construction Grade ApplicationsTemperature Range: -4ºF to +176ºF (-20ºC to +80ºC)

Installation 0

Conduit used with standard liquid-tight connector for easy installation. IP 67 Rated when installed with approved connectors. Delivers superior wiring protection where agency approvals are not required. Manufactured in a full range of trade sizes from 1/4" through 6". Conduit sizes 2-1/2", 3", 3-1/2", and 4" are Type UA/EFST. Smooth appearing jacket for exposed applications. Rated for temperature range of -4ºF to +176ºF (20ºC to +80ºC). Provides liquid-tight raceway for electrical conductors.

Specifications Approx Inside Bend Radius

15 in | 381 mm

Specifications Approx Weight Per 100 Ft

255 lbs | 115.67 kg

Specifications Color

GRAY

Specifications Core Material

Galvanized Steel

Specifications Cross Reference

28105 | LA-18 | LT-18

Specifications Electrical Trade Size

3 in | 78 mm

Specifications Industry Certifications

RoHS WEEE

Specifications Ingress Protection Ip Rating

Ingress Protection (IP) 66/67

Specifications Inside Diameter

3.070 to 3.100 in | 77.978 to 78.740 mm

Specifications Jacket Benefits

Liquid Tight

Specifications Jacket Material

Polyvinyl Chloride (PVC)

Specifications Length

100 ft | 30.48 m

Specifications Optional Colors

Black

Specifications Outside Diameter

3.460 to 3.500 in | 87.884 to 88.900 mm

Specifications Packaging

Standard Coils

Specifications Type

EFST

Liquid Tight Flexible Metal Conduit - Type EFST
