Low Friction-EXT Push-Pull Standard Cable

Low Friction-EXT Push-Pull Standard Cable

SKU:PUS-eaa867

High-efficiency Low Friction-EXT cable for precise control and durability in push-pull mechanisms. Stainless steel end rods with customizable features.

Regular price $29.99
Regular price Sale price $29.99
Sale

Initiate Order

Low Friction-EXT Push-Pull Standard Cable

Low Friction-EXT Push-Pull Standard Cable

$29.99

Quantity: 1

Claim Your Seller Account

Low Friction-EXT Push-Pull Standard Cable

Low Friction-EXT Push-Pull Standard Cable

$29.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Low Friction-EXT Push-Pull Standard Cable is designed for superior efficiency, featuring stainless steel end rods and an extruded nylon cover for smooth operation. With options for seal types, threaded end rod sizes, conduit cap types, and customizable features, this cable ensures precision control and durability. Compliant with Federal/DoD procurement standards, FAR compliance factors, and meets industry-specific certifications.

Product Specifications

Specifications Cable Travel
1 " | 2 " | 3 " | 4 " | 5 " | 6 "
Specifications Conduit Cap Types Options Gg Tg Tt Cc
T - Threaded Swivel/G - Grooved Swivel
Specifications Conduit Description
Low Friction EXT: “The Green Cable” is the proper cable to use when superior efficiency is required. The extruded nylon cover over the innermember works very smoothly with the polyliner (313, 314, 315).
Specifications End Rod Thread Size I
5/16-24
Specifications Seal Options
6
Specifications Suffix Letters For Additional Features
A - Combination of N and W | M - Metric End Rods (optional) | N - End Rod Jam Nuts (2 each) | P - Stamp with Customer Part Number | S - Stamp with Cablecraft and Customer Part Number | W - Extra Shakeproof Washers on Conduit Ends
CAGE
0T9L4
NAICS
332510
PSC
4030
