Low Friction Push-Pull Standard Cable
Low Friction Push-Pull Standard Cable
SKU:PUS-d15fad
High-efficiency Low Friction cable with stainless steel support tubes and precise control options for superior performance.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Low Friction Push-Pull Standard Cable
$39.99
Quantity: 1
Claim Your Seller Account
Low Friction Push-Pull Standard Cable
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Low Friction Push-Pull Standard Cable is designed for superior efficiency, featuring stainless steel support tubes and end rods with a bonded PTFE cover for smooth operation. With options for seal types, end rod thread sizes, and conduit cap configurations, this cable ensures precise control and durability. Meeting stringent industry standards, this cable is ideal for applications requiring high performance and reliability.
Product Specifications
Specifications Cable Travel
1 " | 2 " | 3 " | 4 " | 5 " | 6 "
Specifications Conduit Cap Types Options Gg Tg Tt Cc
T - Threaded Swivel/G - Grooved Swivel
Specifications Conduit Description
Low Friction: The proper cable to use when superior efficiency is required. The bonded PTFE cover over the inner operating member works very smoothly with the plastic liner (183, 184, 185).
Specifications End Rod Thread Size M
M8 x 1.25
Specifications Seal Options
6
Specifications Suffix Letters For Additional Features
A - Combination of N and W | M - Metric End Rods (optional) | N - End Rod Jam Nuts (2 each) | P - Stamp with Customer Part Number | S - Stamp with Cablecraft and Customer Part Number | W - Extra Shakeproof Washers on Conduit Ends
CAGE
0T9L4
NAICS
332510
PSC
4030
