The Low Inertia Air Tube Disc Brakes by Wichita Clutch offer a seamless integration of disc clutch features and direct air engagement advantages. Utilizing compressed air in a specially designed full-circle tube, these brakes deliver exceptional performance with dynamic torque ratings up to 2178000 lb·in | 244980 Nm at 100 psi. With a maximum bore size of 14.00 in | 355 mm and a maximum RPM of 805, these brakes are designed for high-demand applications. Manufactured by Wichita Clutch, these disc brakes ensure reliable operation and efficient actuation through air pressure.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Note 0
Consult Factory for Special Assembly Number.For mounting, use socket head capscrews conforming to the ASTM-574-97a.(Consult factory for drawing before final layout.)
Specifications Actuation
Air Applied
Specifications Assembly Number
6-042-300-302-0
Specifications Dynamic Torque Rating 100 Psi7 Bar
2178000 lb·in | 244980 Nm
Specifications Dynamic Torque Rating 80 Psi55 Bar
1742400 lb·in | 192480 Nm
Specifications Manufacturer
Wichita Clutch
Specifications Maximum Air Pressure
130 psi | 9 bar
Specifications Maximum Bore Size
14.00 in | 355 mm
Specifications Maximum Rpm High Speed Airtube
805 rpm
Specifications Maximum Rpm Standard Airtube
545 rpm
Specifications Total Brake Weight
3704 lb | 1680 kg
Specifications Weight Hub Center Plate
1324 lb | 601 kg
Specifications Wr2jmr2 Hub Center Plate
1809 lb·ft² | 76 kg·m²
