Low Pressure O-Ring Excess Flow Valve - Stainless Steel Construction
Low Pressure O-Ring Excess Flow Valve - Stainless Steel Construction
SKU:MAI-cccbd5
Protect pressure gauges with our Low Pressure O-Ring Excess Flow Valve - Designed for reliability & high performance in demanding environments.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.

The Low Pressure O-Ring Type Excess Flow Valve is designed to safeguard pressure gauges and instrumentation from sudden flow surges caused by operator errors or line failures. Constructed with high-grade 316 Stainless Steel and Viton O-Rings, it ensures reliable shut-off functionality even in high-temperature environments up to 500°F. This valve features a non-spring loaded poppet for vertical installation, resetting automatically when pressure is equalized. With a pressure rating of 15000 psi and an orifice size of 0.250 inches, this valve offers precise control and long-lasting performance. Regular inspections are recommended to maintain optimal O-Ring performance.
Product Specifications
Dimensional Attributes Bore Size
0.690 in
Dimensional Attributes Collar Width
1/2 in
Dimensional Attributes Flange Od
1.125 in
Dimensional Attributes Hub Diametercollar Bore Size
1.000 in
Dimensional Attributes Pipe Size
3/8 in
Dimensional Attributes Total Width
0.568 in
Specifications Approximate Weight
0.01 lb
Specifications Color
White
Specifications Country Of Origin
USA
Specifications Material
Nylon
Specifications Part Number
20P014
Specifications Reach Compliant
Yes
Specifications Rohs2 Compliant
Yes
Specifications Series
Solution
Specifications Type
Single Flange
Specifications Upc Code
662786026058
