Lowell Model 103 Ratcheting Crank Wrench, 28mm Bore Gear

Name: Lowell Model 103 Ratcheting Crank Wrench, 28mm Bore Gear
Brand: Lowell Corporation
SKU: RAT-07f2a9
Price: 79.99 USD
Availability: OutOfStock

SKU:RAT-07f2a9

Enhance machinery adjustments with the Lowell Model 103 Ratcheting Crank Wrench. Durable design, versatile applications, and reversing control for safety.

$79.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Lowell Model 103 Ratcheting Crank Wrench with a 28mm Bore Gear Opening offers exceptional efficiency in machinery adjustments. With a fixed or rotating metal handle for durability, Lowell's bolt-through design allows for secure nut fastening on any threaded length. This versatile tool handles various adjustments including cross feed, rise and fall, gib and quill, and more. Made in the USA, this wrench features a reversing control in the head for safe and convenient operation.

Product Specifications

Specifications Gear Dimension A

1.840 in | 46.7 mm

Specifications Gear Dimension B

2.329 in | 59.2 mm

Specifications Gear Dimension C

.504 in | 12.8 mm

Specifications Gear Dimension D

.885 in | 22.5 mm

Specifications Gear Opening Shape

Bore

Specifications Gear Opening Size

28 mm

Specifications Gear Part Number

M9528

Specifications Handle Nominal Length A

12 in | 305 mm

Specifications Handle Part Number

829L1

Specifications Model

103

Specifications Number Of Teeth

Specifications Weight

2 1/4 lb | 1.02 kg

Specifications Wrench Handle Dimension A

1 1/8 in | 28.6 mm

Specifications Wrench Handle Dimension B

3 11/16 in | 68.3 mm

Specifications Wrench Handle Dimension C

3/4 in | 19.0 mm

Specifications Wrench Handle Length

Long

Specifications Wrench Handle Material

Plastic

Specifications Wrench Handle Type

Fixed | Revolving

Lowell Model 103 Ratcheting Crank Wrench, 28mm Bore Gear
