These pads measure 4 in x 4 in and are 5/8 in thick. Shore A Durometer is 50 +/- 10. Made from custom blended neoprene and Acrylonitrile Butadiene Styrene (ABS Plastic), they are designed to resist chemicals, solvents and water. Reduces vibration, noise and prolongs equipment life.
Product Specifications
General Capabilities Capabilities
Our pads are custom cut – NOT CUSTOM PRICED – to your specifications. Since we design all of our pads to address your individual situation, we have the capability of performing JIT delivery. Using templates, CAD drawings or any form of information you have, we work with you one-on-one to isolate the issue.The LP-13 Shake Absorber® is available in two thickness options: 5/8 in 3/4 in
General Capabilities Full Sheet Size
22 in x 40 in
General Capabilities How We Do It
Our technical and sales teams work with you to determine the appropriate size for your application. We gather several important clues from you to do this: The number and size of feet or “legs” on your equipment or machine The weight of the equipment or machine Its current RPM’s Floor and building structure where the equipment resides
General Capabilities Materialscomposition
The properties that set the LP-13 Shake Absorber® apart from ordinary vibration pads consists of a recycled layer of plastic or Acrylonitrile Butadiene Styrene (ABS) between two layers of very tough, but flexible custom blended neoprene. The cushion dampens machine vibration while the ABS evenly distributes the weight of the machine throughout the pad. We measure our custom blended neoprene using the Shore “A” Durometer scale and ranges from 40 to 80 Shore “A” Durometer. Your individual application dictates your range.
Specifications Abrasion Resistance
Good
Specifications Coefficient Of Friction
Static: .999 u
Specifications Color
Black
Specifications Damping Coefficient Max Load
at 10 Hz: 48.84 N-Sec/mm
Specifications Deflection Displacement
at 25 PSI = .42 mmat 50 PSI = .80 mmat 75 PSI = 1.40 mmat 100 PSI = 1.96 mm
Specifications Density
64.64 lbs/cu. ft.
Specifications Flame Resistance
Good
Specifications Kinetic
.988 u
Specifications List Price
8.80 USD
Specifications Materials
ABS Plastic and Neoprene
Specifications Max Load
100 PSI at 10 Hz
Specifications Oil Resistance
Good
Specifications Shore A Durometer
50
Specifications Size
4 in x 4 in
Specifications Temperature Range
-40 degrees F to +200 degrees F
Specifications Tensile Strength
1100 PSI
Specifications Thickness
5/8 in
Specifications Uv Resistance
Excellent
Specifications Water Absorption By Weight
< 3 %
Specifications Weight
2.02 lbs/sq. ft.
