LP-13 SHAKE ABSORBER® Pad
LP-13 SHAKE ABSORBER® Pad
SKU:LP1-e5a7ae
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
LP-13 SHAKE ABSORBER® Pad
$49.99
Quantity: 1
Claim Your Seller Account
LP-13 SHAKE ABSORBER® Pad
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
These pads measure 12 in x 12 in and are 3/4 in thick. Shore A Durometer is 50 +/- 10. Made from custom blended neoprene and Acrylonitrile Butadiene Styrene (ABS Plastic), they are designed to resist chemicals, solvents and water. Reduces vibration, noise and prolongs equipment life.
Product Specifications
General Capabilities Capabilities
Our pads are custom cut – NOT CUSTOM PRICED – to your specifications. Since we design all of our pads to address your individual situation, we have the capability of performing JIT delivery. Using templates, CAD drawings or any form of information you have, we work with you one-on-one to isolate the issue.The LP-13 Shake Absorber® is available in two different thickness options: 5/8 in 3/4 in
General Capabilities Full Sheet Size
22 in x 40 in
General Capabilities How We Do It
The properties that set the LP-13 Shake Absorber® apart from ordinary vibration pads consists of a recycled layer of plastic or Acrylonitrile Butadiene Styrene (ABS) between two layers of very tough, but flexible custom blended neoprene. The cushion dampens machine vibration while the ABS evenly distributes the weight of the machine throughout the pad. We measure our custom blended neoprene using the Shore “A” Durometer scale and ranges from 40 to 80 Shore “A” Durometer. Your individual application dictates your range.
General Capabilities Materialscomposition
The properties that set the LP-13 Shake Absorber® apart from ordinary vibration pads consists of a recycled layer of plastic or Acrylonitrile Butadiene Styrene (ABS) between two layers of very tough, but flexible custom blended neoprene. The cushion dampens machine vibration while the ABS evenly distributes the weight of the machine throughout the pad. We measure our custom blended neoprene using the Shore “A” Durometer scale and ranges from 40 to 80 Shore “A” Durometer. Your individual application dictates your range.
Specifications Abrasion Resistance
Good
Specifications Coefficient Of Friction
Static: .831 u
Specifications Color
Black
Specifications Damping Coefficient Max Load
at 10 Hz: 24.46 N-Sec/mm
Specifications Deflection Displacement
at 25 PSI = .44 mmat 50 PSI = .96 mmat 75 PSI = 1.92 mmat 100 PSI = 2.99 mm
Specifications Density
60.0 lbs/cu. ft.
Specifications Flame Resistance
Good
Specifications Kinetic
.759 u
Specifications List Price
84.60 USD
Specifications Materials
ABS Plastic and Neoprene
Specifications Max Load
100 PSI at 10 Hz
Specifications Oil Resistance
Good
Specifications Shore A Durometer
50
Specifications Size
12 in x 12 in
Specifications Temperature Range
-40 degrees F to +200 degrees F
Specifications Tensile Strength
1800 PSI
Specifications Thickness
3/4 in
Specifications Uv Resistance
Excellent
Specifications Water Absorption By Weight
< 5 %
Specifications Weight
3.75 lbs/sq. ft.
