LP Series Low Profile Platform Scale with Weight Indicator

Name: LP Series Low Profile Platform Scale with Weight Indicator
Brand: American Scale & Equipment Co.
SKU: FLO-da4dbd
Price: 2899.99 USD
Availability: OutOfStock

SKU:FLO-da4dbd

High-capacity, low-profile platform scale with weight sensors for legal-for-trade applications. Various ramp options available.

$2,899.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The LP Series Low Profile Platform Scale is a robust solution designed for a wide range of legal-for-trade applications. With a capacity of 10,000 lb (5,000 kg) and dimensions of 72" x 48", this platform scale is equipped with weight sensors to ensure accurate measurements. It includes various ramp options for added convenience and is compliant with Legal-for-Trade standards (CoC 88-222, Class III, 5,000 Divisions). When ordering, specify dimensions and interface cable connections to suit your specific requirements.

Product Specifications

Options Accessories

[15923-0325] - Platform lifting eye (must be requested at time of order) On all decks with a width dimension of less than 60", two (2) lifting eyes may be ordered at no additional charge. Decks with a width dimension of 60" or more may be ordered with four (4) lifting eyes at no additional charge. | Extra interface cable

Options Options

When remote mounting the junction box from scale, add for 25' weigh bar cables

Specifications Capacity

10,000 lb | 5,000 kg

Specifications Height

2 in | 5 cm

Specifications Length

72 in

Specifications Model Number

LP7248-10

Specifications Notes

When ordering ramps match the ramp width to the scale width

Specifications Ramps

14198-0011, 84" Ramp | 19124-0019, 48" Ramp | 19124-0035, 60" Ramp | 19124-0050, 72" Ramp

Specifications Shipping Weight

970 lb | 439 kg

Specifications Width

48 in
