The Magnetic Coolant Filtration System is a high-performance solution designed for centralized coolant systems. It features a powerful 1/4 hp motor with specifications including Motor Power: 1/4 hp, Motor Input Voltage (AC): 115 V, Motor Frequency: 60 Hz, Motor Speed: 12 rpm, and a Capacity of 100 gpm. With a 12-inch diameter by 36-inch wide magnetic drum and a screw conveyor for efficient swarf removal, this system ensures clean coolant for uniform part finish, extended tool and grinding wheel lifespan, reduced machine wear, lower coolant replacement costs, and minimized downtime. Consult the factory for custom sizes to meet specific application needs.
Product Specifications
Manufacturing Notes 0
Listed are the most popular sizes. For special applications consult the factory
Specifications Advantages
Having clean coolant is cost effective. Not only does it allow uniform part finish, but you can expect longer life from tools and grinding wheels, reduced pump and machine wear, lower coolant replacement costs, and less down time.
Specifications Capacity
100 gpm
Specifications Dimension A
42 1/2 in
Specifications Dimension B
47 1/2 in
Specifications Magnetic Drum Diameter
12 in
Specifications Magnetic Drum Width
36 in
Specifications Motor Frequency
60 Hz
Specifications Motor Input Voltage Ac
115 V
Specifications Motor Power
1/4 hp
Specifications Motor Speed
12 rpm
Specifications Weight
475 lb
