Marathon Washdown Duty Stainless Steel Electric Motor
Marathon Washdown Duty Stainless Steel Electric Motor
SKU:ELE-43476b
Powerful and corrosion-resistant stainless steel motor for demanding industrial applications. UL Recognized, CSA Certified, and CE Marked.
Regular price
$789.99
Regular price
Sale price
$789.99
Unit price
per
Initiate Order
Marathon Washdown Duty Stainless Steel Electric Motor
$789.99
Quantity: 1
Claim Your Seller Account
Marathon Washdown Duty Stainless Steel Electric Motor
$789.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Marathon Electric Powerwash™ SXT Washdown Duty Motor is designed for stringent sanitation requirements in pharmaceutical, food processing, and chemical industries. Featuring an all stainless steel, totally enclosed C-Face with a rigid base, this motor offers 10:1 variable torque and 20:1 constant torque. With a 300 Series Stainless steel construction and MAX GUARD™ Class F insulation system, it ensures superior corrosion resistance and durability. UL Recognized, CSA Certified, CE Marked, and fully compliant with industry standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications 0
Pharmaceutical IndustriesFood Processing IndustriesChemical Processing Industries (nitric acid and caustic lye may be present)
Features 0
10:1 Variable torque, 20:1 constant torque, 1.0 service factor on VFD.MAX GUARD" Class F insulation system.300 Series Stainless steel external construction: frame, endshields, shaft, conduit box cover, base and hardware for superior corrosion resistance.Double sealed ball bearings with moisture resistant, high temperature grease.Fully coated interior to guard against moisture and corrosion.100% Paint-free construction.Four condensate drains in each endshield.Fully gasketed conduit box, rubber covered oil seals on both shaft extensions.Rated 60/50 hertz, 190/380 volt at next lower horsepower.Nameplate information laser etched on frame.UL Recognized and CSA Certified, CE Mark.
Note 0
Prices and specifications are subject to change without notice. | Prices and specifications are subject to change without notice. | Prices and specifications are subject to change without notice.|Prices and specifications are subject to change without notice.
Specifications Approx Weight
28 lbs
Specifications Category
Washdown Duty
Specifications Dim C
9.40
Specifications Frame
56C
Specifications Full Load Ampere Fla
.75 amps | 1.6-1.5 amps
Specifications Horsepower
1/2
Specifications Manufacturer
Marathon Electric
Specifications Model Number
56T34VD5302
Specifications Motor Type
Powerwash⢠SXT Washdown Duty, Three Phase
Specifications Multiplier Symbol
F3
Specifications Nominal Efficiency
77.0
Specifications Phase
3
Specifications Rpm
3600 rpm
Specifications Service Factor
1.00
Specifications Stock Model
Yes
Specifications Style
All Stainless Steel, Totally Enclosed, C-Face with Rigid Base
Specifications Voltage
208-230 volts | 460 volts
