MARTIN® IN-LINE Chevron Belt Cleaner - Belt Conveyor Cleaning Solution

Name: MARTIN® IN-LINE Chevron Belt Cleaner - Belt Conveyor Cleaning Solution
Brand: Airmatic
SKU: BEL-db1c2b
Price: 699.99 USD
Availability: OutOfStock

SKU:BEL-db1c2b

Efficiently remove carryback with the MARTIN® IN-LINE Chevron Belt Cleaner. Ideal for belts with ribs, chevrons, and cleats. Durable blades ensure thorough cleaning.

$699.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The MARTIN® IN-LINE Chevron Belt Cleaner is a top-tier solution for efficiently removing carryback on belts with ribs, chevrons, and cleats. Featuring durable rubber or urethane blades, this cleaner not only ensures thorough cleaning but also minimizes material buildup. The MARTIN® TORSION ARM™ with 30º-offset arms enhances performance, making it ideal for handling stringy materials like vines, wire, or bark. With dimensions suitable for belt widths of 18 inches and a blade wear life of up to 2 inches, this cleaner offers optimal efficiency and longevity. *Tensioner sold separately.

Product Specifications

Dimensions Belt Width

18 in | 400 to 500 mm

Dimensions Blade Width A

14 in | 356 mm

Dimensions Max Mainframe Length

48 in | 1219 mm

Dimensions Of Blades

Dimensions Shipping Weight

55 lb | 24.9 kg

Specifications Blade Type

Urethane

Specifications Blade Wear Life

2 in | 50 mm

Specifications Max Belt Speed

500 fpm | 2.50 m/s

Specifications Max Height

0.50 in | 13 mm

Specifications Max Service Constant Temperature

150 ÂºF | 65 ÂºC

Specifications Max Service Intermittent Temperature

180 ÂºF | 82 ÂºC

Specifications Mounting Radius

4 in | 102 mm

Specifications Recommended Tensioner

Reversing Mount Spring Tensioner

Specifications Urethane Color

Brown
