MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
SKU:BEL-dbe5b7
Efficiently remove carryback with MARTIN® IN-LINE Chevron Belt Cleaner for stringy materials. Durable blades for reduced clean-up costs.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
$899.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner is designed to effectively remove carryback from belts with ribs, chevrons, and cleats using rubber or urethane blades. Featuring MARTIN® TORSION ARM™ with 30º-offset arms for efficient cleaning. This cleaner is ideal for handling stringy materials like vines, wire, or bark. With a sturdy construction and high-performance blade materials, it ensures extended blade wear life and reduced conveyor clean-up costs. Tensioner sold separately.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
96 in | 2200 to 2400 mm
Dimensions Blade Width A
91 in | 2311 mm
Dimensions Max Mainframe Length
126 in | 2300 mm
Dimensions Of Blades
13
Dimensions Shipping Weight
165 lb | 74.80 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Navy Blue
