MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
SKU:BEL-e8dc77
Efficiently remove carryback debris with MARTIN® IN-LINE Chevron Belt Cleaner for superior belt maintenance.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
$799.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner is designed with rubber or urethane blades to effectively remove carryback and smoothly navigate belts with ribs, chevrons, and cleats. Incorporating 30º-offset arms, this cleaner is ideal for handling stringy materials like vines, wires, or bark that may catch on traditional cleaner arms. The innovative design ensures thorough cleaning without damaging the conveyor belt. Compatible with MARTIN® TORSION ARM™ accessories to optimize performance and extend belt life.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
96 in | 2200 to 2400 mm
Dimensions Blade Width A
91 in | 2311 mm
Dimensions Max Mainframe Length
126 in | 2300 mm
Dimensions Of Blades
13
Dimensions Shipping Weight
165 lb | 74.80 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Green
