MARTIN® IN-LINE Chevron Belt Cleaner - Heavy-Duty Conveyor Cleaning Solution

MARTIN® IN-LINE Chevron Belt Cleaner - Heavy-Duty Conveyor Cleaning Solution

BEL-584294

Effectively remove carryback with MARTIN® IN-LINE Chevron Belt Cleaner - ideal for belt widths up to 800mm. Durable and efficient cleaning solution for heavy-duty conveyor systems.

$349.99
$349.99
Sale

Initiate Order

MARTIN® IN-LINE Chevron Belt Cleaner - Heavy-Duty Conveyor Cleaning Solution

MARTIN® IN-LINE Chevron Belt Cleaner - Heavy-Duty Conveyor Cleaning Solution

$349.99

Quantity: 1

Claim Your Seller Account

MARTIN® IN-LINE Chevron Belt Cleaner - Heavy-Duty Conveyor Cleaning Solution

MARTIN® IN-LINE Chevron Belt Cleaner - Heavy-Duty Conveyor Cleaning Solution

$349.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The MARTIN® IN-LINE Chevron Belt Cleaner is a heavy-duty solution designed to effectively remove carryback while gently maneuvering over belts with ribs, chevrons, and cleats. With rubber or urethane blades, this cleaner is ideal for preventing stringy materials like vines, wire, or bark from catching on its arms. The MARTIN® TORSION ARM™ Chevron Belt Cleaner features 30º-offset arms for efficient cleaning. This cleaner, suitable for belt widths ranging from 30 inches to 800mm, delivers reliable performance and longevity, ensuring minimal conveyor clean-up costs. *Tensioner sold separately.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Dimensions Belt Width
30 in | 650 to 800 mm
Dimensions Blade Width A
28 in | 711 mm
Dimensions Max Mainframe Length
60 in | 1524 mm
Dimensions Of Blades
4
Dimensions Shipping Weight
75 lb | 34 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Tan
