MARTIN® IN-LINE Chevron Belt Cleaner - Urethane Blades
MARTIN® IN-LINE Chevron Belt Cleaner - Urethane Blades
SKU:BEL-a60efc
Efficiently eliminate carryback with the MARTIN® IN-LINE Chevron Belt Cleaner's urethane blades, designed for easy glide over belts with ribs and cleats.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner - Urethane Blades
$349.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner - Urethane Blades
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner with urethane blades is a premium solution for removing carryback effectively while gently gliding over belts with ribs, chevrons, and cleats. Featuring the MARTIN® TORSION ARM™ with 30º-offset arms, this cleaner is ideal for handling stringy materials like vines, wire, or bark that can catch on cleaner arms. With dimensions suitable for belt widths of 24 inches, blade wear life of 2 inches, and a max service temperature of 180ºF, this cleaner ensures optimal performance and durability. The recommended tensioner for this cleaner is the Reversing Mount Spring Tensioner (sold separately).
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
24 in | 500 to 650 mm
Dimensions Blade Width A
21 in | 533 mm
Dimensions Max Mainframe Length
54 in | 1372 mm
Dimensions Of Blades
3
Dimensions Shipping Weight
60 lb | 27.2 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Orange
