MARTIN® IN-LINE Chevron Belt Cleaner with Rubber Blades
MARTIN® IN-LINE Chevron Belt Cleaner with Rubber Blades
SKU:BEL-bb9897
Efficiently remove carryback with the MARTIN® IN-LINE Chevron Belt Cleaner featuring rubber blades for diverse belt types. Ideal for stringy materials.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner with Rubber Blades
$799.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner with Rubber Blades
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner features rubber blades designed to effectively eliminate carryback while navigating belts with ribs, chevrons, and cleats. Equipped with MARTIN® TORSION ARM™ technology with 30º-offset arms, it is ideal for applications with stringy materials like vines, wire, or bark. This cleaner, with dimensions suitable for belt widths of 30 in (650 to 800 mm), offers a long blade wear life of 2 in (50 mm) and is compatible with a reversing mount spring tensioner for optimal performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
30 in | 650 to 800 mm
Dimensions Blade Width A
28 in | 711 mm
Dimensions Max Mainframe Length
60 in | 1524 mm
Dimensions Of Blades
4
Dimensions Shipping Weight
75 lb | 34 kg
Specifications Blade Type
Ruber
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
