MARTIN® XHD Belt Cleaner

MARTIN® XHD Belt Cleaner

BEL-23ccc9

Efficiently clean belts with MARTIN® XHD Belt Cleaner. Reduces carryback & downtime, enhancing productivity.

$899.99
$899.99
Sale

Initiate Order

MARTIN® XHD Belt Cleaner

MARTIN® XHD Belt Cleaner

$899.99

Quantity: 1

Claim Your Seller Account

MARTIN® XHD Belt Cleaner

MARTIN® XHD Belt Cleaner

$899.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The MARTIN® XHD Belt Cleaner is a heavy-duty solution for efficient belt cleaning, designed for belt widths ranging from 18" to 96" and speeds up to 1200 FPM. Featuring massive XHD blades on a steel mandrel, this cleaner reduces carryback, minimizing cleanup tasks, and extending conveyor life. The spring tensioner or air tensioner options allow for quick blade replacement, reducing downtime and enhancing productivity. Built robustly, the MARTIN® XHD Blades withstand tough conditions, making them ideal for heavy material loads and high-speed operations.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Benefits 0
Removes Carryback, Saves CleanupEffective belt cleaning reduces plant cleanup chores and pro longs life of conveyor components.Reduces Downtime for ServiceSlide-in/slide-out mandrel allows quick and easy blade replace ment to increase conveyor availability. With on-site safety ap provals, blades can be changed while the belt runs. Slide-Out/Slide-In Blade ChangeIndividual blade segments slide into sturdy track-forming car tridge. This cartridge slides over stainless steel mainframe into cleaning position. Split Track CartridgeSplit track cartridge design allows simple blade removal even with material accumulation. Built Strong for Tough ConditionsMassive The MARTIN® XHD Blades stand up to challenging condi tions, including heavy material loads and belt speeds up to 1200fpm (6m/sec).
Dimensions Belt Width
36 in
Dimensions Blade Width A
36 in | 914 mm
Dimensions Max Mainframe Length
67.50 in | 1715 mm
Dimensions Of Blades
6
Dimensions Weight Wo Tensioner
142.50 lb
Specifications Blade Type
IN-LINE Tungsten Carbide Blade
Specifications Mainframe Type
Painted
Specifications Tensioner Type
Spring Tensioner
Specifications Urethane Color
Orange
