MARTIN® IN-LINE Chevron Belt Cleaner
MARTIN® IN-LINE Chevron Belt Cleaner
SKU:BEL-316662
Efficiently remove carryback with MARTIN® IN-LINE Chevron Belt Cleaner, ideal for handling stringy materials. Tensioner sold separately.
Regular price
$599.99
Regular price
Sale price
$599.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner
$599.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner
$599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner is designed with rubber or urethane blades to effectively eliminate carryback and navigate belts with ribs, chevrons, and cleats. Featuring 30º-offset arms, it is ideal for handling stringy materials like vines, wire, or bark. This cleaner, with a max service temperature of 180 ºF, ensures efficient belt cleaning and reduced maintenance. Tensioner sold separately.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
72 in | 1800 to 2000 mm
Dimensions Blade Width A
70 in | 1778 mm
Dimensions Max Mainframe Length
102 in | 2591 mm
Dimensions Of Blades
10
Dimensions Shipping Weight
130 lb | 59 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Green
