MARTIN® IN-LINE Chevron Belt Cleaner - Belt Width 36in
MARTIN® IN-LINE Chevron Belt Cleaner - Belt Width 36in
SKU:BEL-9c6a4a
Efficient MARTIN® IN-LINE Chevron Belt Cleaner for thorough carryback removal and gentle cleaning over belts with ribs, chevrons, and cleats.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner - Belt Width 36in
$799.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner - Belt Width 36in
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner is a top-tier solution from the MARTIN® Chevron Cleaners line, featuring rubber or urethane blades for efficient carryback removal. With a design that accommodates belts with ribs, chevrons, and cleats, this cleaner ensures thorough cleaning while preventing material buildup. The innovative MARTIN® TORSION ARM⢠technology, with 30º-offset arms, enhances cleaning efficiency. Ideal for materials prone to catching on cleaner arms like vines, wire, or bark, this cleaner offers reliability and longevity. Note: Tensioner not included and must be ordered separately.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
36 in | 800 to 1000 mm
Dimensions Blade Width A
35 in | 889 mm
Dimensions Max Mainframe Length
66 in | 1676 mm
Dimensions Of Blades
5
Dimensions Shipping Weight
78 lb | 35.40 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Green
