MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
SKU:BEL-743b77
Efficiently remove carryback and tackle stringy materials with MARTIN® IN-LINE Chevron Belt Cleaner – a durable solution for belt conveyor systems.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
$299.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner for Stringy Materials
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner is designed with rubber blades to effectively remove carryback while smoothly navigating ribs, chevrons, and cleats on belts. With MARTIN® TORSION ARM⢠technology featuring 30º-offset arms, this cleaner is ideal for tackling stringy materials like vines, wire, or bark. The cleaner, with dimensions of Belt Width: 24 in and Blade Width: 21 in, offers a durable solution for reducing conveyor clean-up costs and enhancing operational efficiency. Order the tensioner separately for optimal performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
24 in | 500 to 650 mm
Dimensions Blade Width A
21 in | 533 mm
Dimensions Max Mainframe Length
54 in | 1372 mm
Dimensions Of Blades
3
Dimensions Shipping Weight
60 lb | 27.2 kg
Specifications Blade Type
Ruber
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
