MARTIN® IN-LINE Chevron Belt Cleaner with Urethane Blades
MARTIN® IN-LINE Chevron Belt Cleaner with Urethane Blades
SKU:BEL-a7200f
Efficiently remove carryback with MARTIN® IN-LINE Chevron Belt Cleaner with urethane blades. Prevent material buildup for optimal conveyor performance.
Regular price
$1,249.99
Regular price
Sale price
$1,249.99
Unit price
per
Initiate Order
MARTIN® IN-LINE Chevron Belt Cleaner with Urethane Blades
$1,249.99
Quantity: 1
Claim Your Seller Account
MARTIN® IN-LINE Chevron Belt Cleaner with Urethane Blades
$1,249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MARTIN® IN-LINE Chevron Belt Cleaner with urethane blades is designed to efficiently remove carryback from belts with ribs, chevrons, and cleats. With 30º-offset arms, it gently steps over obstructions to ensure thorough cleaning. Ideal for preventing material buildup from vines, wires, or bark, this cleaner offers a blade wear life of 2 inches and is compatible with a Reversing Mount Spring Tensioner. Enhance conveyor performance and reduce clean-up costs with this durable and effective belt cleaner.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Belt Width
96 in | 2200 to 2400 mm
Dimensions Blade Width A
91 in | 2311 mm
Dimensions Max Mainframe Length
126 in | 2300 mm
Dimensions Of Blades
13
Dimensions Shipping Weight
165 lb | 74.80 kg
Specifications Blade Type
Urethane
Specifications Blade Wear Life
2 in | 50 mm
Specifications Max Belt Speed
500 fpm | 2.50 m/s
Specifications Max Height
0.50 in | 13 mm
Specifications Max Service Constant Temperature
150 ºF | 65 ºC
Specifications Max Service Intermittent Temperature
180 ºF | 82 ºC
Specifications Mounting Radius
4 in | 102 mm
Specifications Recommended Tensioner
Reversing Mount Spring Tensioner
Specifications Urethane Color
Brown
