MCX Female Receptacles with Solder End
MCX Female Receptacles with Solder End
SKU:MCX-3ce2f5
High-quality MCX Female Receptacles with 50 ohm impedance, RF leakage protection, and durable design for high-frequency applications.
Regular price
$25.99
Regular price
Sale price
$25.99
Unit price
per
Initiate Order
MCX Female Receptacles with Solder End
$25.99
Quantity: 1
Claim Your Seller Account
MCX Female Receptacles with Solder End
$25.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MCX Female Receptacles with Solder End are precision-engineered connectors designed for high-frequency applications up to 6GHz. With a 50 ohm impedance, these receptacles offer exceptional RF leakage protection, high durability with over 500 matings, and a wide temperature range from -67°F to 311°F. Crafted from high-quality materials like hardened brass, beryllium copper, and PTFE/PFA insulators, these connectors ensure reliable performance under extreme conditions. Ideal for institutional and government procurement, these MCX receptacles meet stringent standards for impedance, voltage tolerances, and contact resistance.
Product Specifications
Specifications Body Material
Brass
Specifications Centre Contact Resistance M Ohms
<5
Specifications Configuration
solder bulkhead
Specifications Connection
female
Specifications Connector Series
MCX
Specifications Contact Captivation Lbs
>2.3
Specifications Crimp Ferrule Material
Copper
Specifications Dielectic Withstanding Voltage Sea Level V Rms
>750
Specifications Disengagement Force Lbs
1.8 to 4.5
Specifications Durability Matings
>500
Specifications Engagement Force Lbs
<5.6
Specifications Frequency Ghz
DC...6
Specifications Grid Inches
ML11
Specifications Impedance Ohms
50
Specifications Insulation Resistance M Ohms
>100000
Specifications Insulator Material
PTFE or PFA
Specifications Outer Contacts Jack
Brass
Specifications Outer Contacts Plug
Beryllium copper, hardened
Specifications Outside Contact Resistance M Ohms
<1
Specifications Packaging
bulk 100 pcs
Specifications Pin Contact Material
Brass
Specifications Plating Body
gold
Specifications Rf Leakage Connectors For Flexible Cables Db
>60
Specifications Rf Leakage Connectors For Semi Rigid Cables Db
>70
Specifications Socket Contact Material
Beryllium copper, hardened
Specifications Temperature Range Degrees F
-67 to 311
Specifications Working Voltage 70000 Ft V Rms
>42
Specifications Working Voltage Sea Level V Rms
>170
