MCX PCB Female Straight Plugs
MCX PCB Female Straight Plugs
SKU:MCX-07be88
High-quality MCX PCB Female Straight Plugs for precise PCB connections with 50 ohm impedance, gold-plated body, and exceptional durability.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
MCX PCB Female Straight Plugs
$49.99
Quantity: 1
Claim Your Seller Account
MCX PCB Female Straight Plugs
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MCX PCB Female Straight Plugs are designed for high-performance PCB connections with a 50 ohm impedance, gold-plated body, and straight configuration. With a frequency range up to 6 GHz, these connectors ensure low RF leakage, exceptional durability with over 500 matings, and wide temperature range compatibility from -67 to 311 degrees Fahrenheit. Crafted from premium materials like brass, beryllium copper, and PTFE/PFA insulators, they offer superior electrical performance and reliability. Ideal for demanding applications where precision and quality are paramount.
Product Specifications
Specifications Body Material
Brass
Specifications Centre Contact Resistance M Ohms
<5
Specifications Configuration
straight
Specifications Connection
female
Specifications Connector Series
MCX
Specifications Contact Captivation Lbs
>2.3
Specifications Crimp Ferrule Material
Copper
Specifications Dielectic Withstanding Voltage Sea Level V Rms
>750
Specifications Disengagement Force Lbs
1.8 to 4.5
Specifications Durability Matings
>500
Specifications Engagement Force Lbs
<5.6
Specifications Frequency Ghz
DC...6
Specifications Grid Inches
.05
Specifications Impedance Ohms
50
Specifications Insulation Resistance M Ohms
>100000
Specifications Insulator Material
PTFE or PFA
Specifications Mount
without standoff
Specifications Mounting Hole
ML 44
Specifications Outer Contacts Jack
Brass
Specifications Outer Contacts Plug
Beryllium copper, hardened
Specifications Outside Contact Resistance M Ohms
<1
Specifications Packaging
bulk 100 pcs.
Specifications Pin Contact Material
Brass
Specifications Plating Body
gold
Specifications Rf Leakage Connectors For Flexible Cables Db
>60
Specifications Rf Leakage Connectors For Semi Rigid Cables Db
>70
Specifications Socket Contact Material
Beryllium copper, hardened
Specifications Temperature Range Degrees F
-67 to 311
Specifications Working Voltage 70000 Ft V Rms
>42
Specifications Working Voltage Sea Level V Rms
>170
