MCX Right Angle PCB Plug-Female (50 Ohm, Gold Plated, Bulk Pack of 100)
MCX Right Angle PCB Plug-Female (50 Ohm, Gold Plated, Bulk Pack of 100)
SKU:MCX-e3fff4
Enhance your PCB setups with precision-engineered MCX Right Angle PCB Plugs: Female (50 Ohm, Gold Plated).
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
MCX Right Angle PCB Plug-Female (50 Ohm, Gold Plated, Bulk Pack of 100)
$149.99
Quantity: 1
Claim Your Seller Account
MCX Right Angle PCB Plug-Female (50 Ohm, Gold Plated, Bulk Pack of 100)
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your PCB connections with our precision-engineered MCX Right Angle PCB Plugs (female). Featuring a gold-plated body for optimal signal transmission, these connectors ensure a secure and reliable connection. With a 50-ohm impedance, DC to 6 GHz frequency range, and high durability of over 500 matings, these plugs are designed to meet the most demanding requirements of both consumer and institutional applications. Expertly crafted from high-quality materials such as brass, beryllium copper, and PTFE/PFA insulators, these connectors guarantee exceptional performance in extreme temperatures from -67 to 311 degrees Fahrenheit.
Product Specifications
Specifications Body Material
Brass
Specifications Centre Contact Resistance M Ohms
<5
Specifications Configuration
right angle
Specifications Connection
female
Specifications Connector Series
MCX
Specifications Contact Captivation Lbs
>2.3
Specifications Crimp Ferrule Material
Copper
Specifications Dielectic Withstanding Voltage Sea Level V Rms
>750
Specifications Disengagement Force Lbs
1.8 to 4.5
Specifications Durability Matings
>500
Specifications Engagement Force Lbs
<5.6
Specifications Frequency Ghz
DC...6
Specifications Grid Inches
.100
Specifications Impedance Ohms
50
Specifications Insulation Resistance M Ohms
>100000
Specifications Insulator Material
PTFE or PFA
Specifications Mounting Hole
ML 15
Specifications Outer Contacts Jack
Brass
Specifications Outer Contacts Plug
Beryllium copper, hardened
Specifications Outside Contact Resistance M Ohms
<1
Specifications Packaging
bulk 100 pcs.
Specifications Pin Contact Material
Brass
Specifications Plating Body
gold
Specifications Rf Leakage Connectors For Flexible Cables Db
>60
Specifications Rf Leakage Connectors For Semi Rigid Cables Db
>70
Specifications Socket Contact Material
Beryllium copper, hardened
Specifications Temperature Range Degrees F
-67 to 311
Specifications Working Voltage 70000 Ft V Rms
>42
Specifications Working Voltage Sea Level V Rms
>170
