MCX Right Angle PCB Plugs, Female - Bulk 100 pcs
MCX Right Angle PCB Plugs, Female - Bulk 100 pcs
SKU:MCX-7d6659
MCX Right Angle PCB Plugs - High-frequency, gold-plated, 50 ohm connectors for reliable signal transmission.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
MCX Right Angle PCB Plugs, Female - Bulk 100 pcs
$99.99
Quantity: 1
Claim Your Seller Account
MCX Right Angle PCB Plugs, Female - Bulk 100 pcs
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MCX Right Angle PCB Plugs are precision-engineered connectors designed to meet the demanding requirements of high-frequency applications. With a 50 ohm impedance, gold-plated body, and right-angle configuration, these connectors ensure reliable signal transmission and durability. Featuring RF leakage reduction capabilities, high voltage tolerance, and a wide temperature range (-67 to 311°F), they are suitable for diverse environments. Crafted from quality materials like brass, beryllium copper, and PTFE insulators, these connectors offer superior performance and longevity. Compliant with industry standards, these connectors are ideal for both consumer and institutional procurement needs.
Product Specifications
Specifications Body Material
Brass
Specifications Centre Contact Resistance M Ohms
<5
Specifications Configuration
right angle
Specifications Connection
female
Specifications Connector Series
MCX
Specifications Contact Captivation Lbs
>2.3
Specifications Crimp Ferrule Material
Copper
Specifications Dielectic Withstanding Voltage Sea Level V Rms
>750
Specifications Disengagement Force Lbs
1.8 to 4.5
Specifications Durability Matings
>500
Specifications Engagement Force Lbs
<5.6
Specifications Frequency Ghz
DC...6
Specifications Impedance Ohms
50
Specifications Insulation Resistance M Ohms
>100000
Specifications Insulator Material
PTFE or PFA
Specifications Mount
surface mount
Specifications Mounting Hole
ML 123
Specifications Outer Contacts Jack
Brass
Specifications Outer Contacts Plug
Beryllium copper, hardened
Specifications Outside Contact Resistance M Ohms
<1
Specifications Packaging
bulk 100 pcs.
Specifications Pin Contact Material
Brass
Specifications Plating Body
gold
Specifications Rf Leakage Connectors For Flexible Cables Db
>60
Specifications Rf Leakage Connectors For Semi Rigid Cables Db
>70
Specifications Socket Contact Material
Beryllium copper, hardened
Specifications Temperature Range Degrees F
-67 to 311
Specifications Working Voltage 70000 Ft V Rms
>42
Specifications Working Voltage Sea Level V Rms
>170
