Medical Grade Isolation Power Transformers
Medical Grade Isolation Power Transformers
SKU:POW-0bffba
Ensure safety and reliability with our Medical Grade Isolation Power Transformers. Ideal for medical equipment applications.
Regular price
$199.99
Regular price
Sale price
$199.99
Unit price
per
Initiate Order
Medical Grade Isolation Power Transformers
$199.99
Quantity: 1
Claim Your Seller Account
Medical Grade Isolation Power Transformers
$199.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Medical Grade Isolation Power Transformers provide a safe and reliable solution for isolating equipment from direct power connections. Designed to meet low leakage current requirements, these transformers are ideal for medical equipment applications. Featuring nonconcentrically wound coils, separate primary and secondary windings, and a resettable circuit breaker for overload protection, our hospital type transformers ensure utmost safety and performance.
Product Specifications
Note Note
Split winding
Specifications Case Type
A
Specifications Connections
Leads
Specifications Depth D
4 5/8 in
Specifications Height H
4 5/8 in
Specifications Lead Holes Used
2
Specifications Mounting Depth
3 5/8 in
Specifications Mounting Hole Size
3/8 x 3/16 in
Specifications Mounting Width
3 in
Specifications Output Wattage Va Rating
250 W
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V | 230 V
Specifications Secondary Current
2.170 A
Specifications Secondary Voltage 5
115 V
Specifications Weight
11.00 lb
Specifications Width W
3 15/16 in
Technical Notes Technical Notes
Line cord, plug and receptacle are U.L. listed and verified to meet federal specifications.Connections are by leads, plugs and sockets.Hi-pot tested at 1,500 VRMS.
