The Mega-Orlock 6.8 Series 27.0mm Body Length Triple Locking Head Rivet is a high-strength solution designed for chassis assembly. Featuring a patented triple-locking system, this rivet ensures ultra-high shear forces, providing durability and reliability in demanding environments. With low carbon steel construction, zinc-plated chromium VI free passivation, and meeting stringent technical specifications, this rivet offers exceptional performance and longevity. Ideal for rail transport applications, this Ornit innovation reduces stock inventories while guaranteeing secure fastening.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Rail Transport Application
Rail Transport - TrainsThe Mega Orlock® fastener, Ornit's latest innovation, features a patented triple-locking system, designed to provide ultra-high shear and tensile forces. This unique product helps to reduce stock inventories.
Nominal Dimensions Body Length
27.0 mm | 1.063 in
Nominal Dimensions Diameter
8.6 mm | 5/16 in
Nominal Dimensions Drillhole Size
8.9 to 9.3 mm | 0.350 to 0.366 in
Nominal Dimensions Head Diameter
12.0 mm | 0.472 in
Nominal Dimensions Head Thickness
6.9 mm | 0.272 in
Nominal Dimensions Mandrel Diameter
5.8 mm | 0.228 in
Nominal Dimensions Maximum Grip Range
17.5 mm | 0.689 in
Nominal Dimensions Minimum Grip Range
14.3 mm | 0.563 in
Nominal Forces Nominal Shear Force
3200 kgf | 7056 lbf
Nominal Forces Nominal Tensile Force
2160 kgf | 4763 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free Passivation
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Mega-Orlock® | Ornit
Technical Specs Carton Quantity
1500
Technical Specs Head Style
Triple Locking System
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free Passivation
Technical Specs Mandrel Material
Carbon Steel
