Metal Threaded Check Valve with Fluorocarbon Seal

Name: Metal Threaded Check Valve with Fluorocarbon Seal
Brand: O'Keefe Controls Co.
SKU: CHE-e3d591
Price: 29.99 USD
Availability: OutOfStock

SKU:CHE-e3d591

Durable Metal Threaded Check Valve with Fluorocarbon Seal for reliable flow control. Meets industry standards.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Experience reliable flow control with our Metal Threaded Check Valve featuring a Fluorocarbon seal. Constructed with 303 SS material and a 440C-SS ball, this valve ensures durability and longevity. With a maximum operating pressure of 1400 kPa and minimal seat leakage, it meets stringent industry standards for performance and quality, making it ideal for institutional and government procurement needs.

Product Specifications

Dimensions Nose Diameter

5.59 mm

Dimensions Orifice Diameter

0.0670 in | 1.7 mm

Dimensions Thread Size

Dimensions Total Length

16.3 mm

Dimensions Width Across Flats Hex

4 mm

Features Features

All metal construction option Long life operation Low cost

Specifications Ball Material

440C-SS

Specifications Connection A

M8 Threaded Insert O-Ring seal

Specifications Cv

0.100

Specifications Hex Type

Internal

Specifications Material

303 SS

Specifications Maximum Operating Pressure

1400 kPa

Specifications Nominal Orifice Size

Specifications Screened

None

Specifications Seal Material

Fluorocarbon

Specifications Seat Leakage

20 SSCM (max.) air flow at 25 psi differential

Specifications Thread

Male

Metal Threaded Check Valve with Fluorocarbon Seal
