Metric Threaded Body Air Cylinders
Metric Threaded Body Air Cylinders
SKU:AIR-8f1d43
High-performance Metric Threaded Body Air Cylinders for precise industrial applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Metric Threaded Body Air Cylinders
$129.99
Quantity: 1
Claim Your Seller Account
Metric Threaded Body Air Cylinders
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your industrial automation processes with our Threaded Body Metric Air Cylinders. Available in standard, intermediate, and heavy-duty types to suit diverse applications. These cylinders, crafted from aluminum and steel, offer stroke travel from 2.5mm to 25mm and bore sizes ranging from 8mm to 20mm. With operating pressures from 8 to 30 bar, they ensure reliable and efficient performance. Choose from various actuation types and optional mounting options for seamless integration.
Product Specifications
Features Features
Double End Rod (Optional)Multi-position
Heavy Duty Full Husky Heavy Duty Full Husky
Longer rod bearing plus longer piston. Designed for heavy duty services. Available as single or double rod end.
Intermediate Duty Half Husky Intermediate Duty Half Husky
A combination of our standard and Heavy duty. long rod bearing and thin piston, designed for medium duty service. Available as single or double rod end.
Specifications Actuation Type
Pneumatic
Specifications Bore Size High
20 mm
Specifications Bore Size Low
8 mm
Specifications Cylinder Type
Air Cylinder
Specifications Device Type
Linear Actuator | Rod Type
Specifications Material
Aluminum | Steel
Specifications Mounting Type
Face Mount (Optional) | Rear Mount (Optional) | Threaded (Optional)
Specifications Operating Pressure High
30 bar
Specifications Operating Pressure Low
8 bar
Specifications Stroke Or X Axis Travel High
25 mm
Specifications Stroke Or X Axis Travel Low
2.5 mm
Standard Duty Standard Duty
Our most space efficient duty. Short rod bearing and thin piston design. Available as single or double rod end.
