microPEM® TackSert⢠Type TK™ Pins for Metal Sheets and Panels
microPEM® TackSert⢠Type TK™ Pins for Metal Sheets and Panels
SKU:PEM-666ac1
Securely attach thin sheets to plastics and casting materials with ease using the microPEM® TackSert™ Type TK™ Pins.
Regular price
$14.99
Regular price
Sale price
$14.99
Unit price
per
Initiate Order
microPEM® TackSert⢠Type TK™ Pins for Metal Sheets and Panels
$14.99
Quantity: 1
Claim Your Seller Account
microPEM® TackSert⢠Type TK™ Pins for Metal Sheets and Panels
$14.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The microPEM® TackSert™ Type TK™ Pins are designed for securely attaching thin sheets to plastics, common casting materials, and more. Perfect for compact electronics, these pins offer a reliable alternative to screws, eliminating the need for tapping or threaded inserts. With a tapered tip for easy alignment and a low-profile head, these pins ensure a simple, press-in installation without requiring heat or ultrasonics. Ideal for attaching panels to plastics such as ABS and magnesium die casting materials like AZ91D.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Base Panel Hole Size
0.039 in -.002 in | 1 mm -0.05 mm
Specifications Base Panel Hole Size Code
10
Specifications C Max
1.2 mm | .047 in
Specifications For Use In
P.C. Board and Plastics
Specifications H
0.071 in ±.003 in | 1.8 mm ±0.08 mm
Specifications L
0.118 in ±.002 in | 3 mm ±0.06 mm
Specifications Length Code
300
Specifications Material
Aluminum
Specifications Min Dist Hole Cl To Edge
1.18 mm | .047 in
Specifications Standard Finish
Plain
Specifications T
0.011 in ±.003 in | 0.27 mm ±0.08 mm
Specifications Top Sheet Hole Size
0.051 in ±.002 in | 1.3 mm ±0.05 mm
Specifications Top Sheet Thickness Max
2.2 mm | .087 in
Specifications Type
TKA
