MIL-DTL-83420 Type II Comp B

Name: MIL-DTL-83420 Type II Comp B
Brand: Lexco Cable Manufacturing
SKU: WIR-870ce6
Price: 49.99 USD
Availability: OutOfStock

SKU:WIR-870ce6

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Type II, Comp B Warning: Wire rope & aircraft cable should never be used at breaking strength. 10:1 safety factor minimum is recommended for critical/overhead application. Do not use for overhead lifting without consulting a wire rope rigging professional. End fittings may not hold to 100% of strength efficiency so a safety factor such as 5:1 should be divided into the assembly actual strength. A pull test is recommended for quality assurance.

Product Specifications

Specifications Construction

7 x 19

Specifications Dia In

7/32

Specifications Material

Stainless steel

Specifications Mbs Composition B

5000 lbs

Specifications Nylon Od In

11/32

MIL-DTL-83420 Type II Comp B
