Mitutoyo 543-310B Digimatic Bore Gage

Name: Mitutoyo 543-310B Digimatic Bore Gage
Brand: Penn Tool Co.
SKU: BOR-8399e6
Price: 899.99 USD
Availability: OutOfStock

SKU:BOR-8399e6

Precision Mitutoyo 543-310B Bore Gage for accurate bore measurements. Features LCD, Absolute Linear Encoder, and long battery life.

$899.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Mitutoyo 543-310B Bore Gage is a precision instrument designed for accurate bore measurement applications. Featuring a range of 12.7mm and an accuracy of 0.003mm, this gage ensures reliable and consistent results. Equipped with a liquid crystal display, Absolute Electrostatic Capacitance Type Linear Encoder, and a battery life of approximately 12 months, it offers efficient and user-friendly operation. Additionally, it comes with accessories like SPC Connecting Cables for enhanced connectivity.

Product Specifications

Accessories 2 Accessories 2

Item # - 905338Item Name - Mitutoyo SPC Connecting Cable (1m)/ 40" - 905338Description - UPC 603908186632 All CALIPERS WITHOUT ABSOLUTE ENCODER Height Gage 570-2XX, 192-6XX, 192-67X Indicators 575-XXX, 543-6XX, 543-2XX, 543-4XX Depth Gages 547-21X, 547-25X, 571-2XX Scale Unit 572-XXX Thickness Gages 547-3XX, 547-4XX

Accessories 3 Accessories 3

Item # - 905409Item Name - Mitutoyo SPC Connecting Cable (2m) - 905409

Technical Specs Accuracy

0.003 in | 0.003 mm

Technical Specs Battery Life

Approximate 12 months under normal use

Technical Specs Battery Type

CR2032 (1 pc.), 05SAA217

Technical Specs Brands

Mitutoyo

Technical Specs Delivery Scope

Item # - 21EZA313Item Name - Mitutoyo USB cable and Outline of Parameter Setting Software - 21EZA313

Technical Specs Display

Liquid crystal display (LCD)

Technical Specs Ingress Protection Ip Rating

Equivalent to IP-42*1

Technical Specs Maximum Response Speed

Unlimited

Technical Specs Measuring Force

1.5N or less

Technical Specs Model

ID-C112GXB

Technical Specs Range

12.7 mm

Technical Specs Standard Length

Absolute Electrostatic Capacitance Type Linear Encoder

Mitutoyo 543-310B Digimatic Bore Gage
