Mitutoyo 543-311B Bore Gage with Digimatic Indicator
Mitutoyo 543-311B Bore Gage with Digimatic Indicator
SKU:BOR-092239
Mitutoyo 543-311B Bore Gage - Accurate, Reliable, and User-Friendly for Precision Measurements
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
Mitutoyo 543-311B Bore Gage with Digimatic Indicator
$799.99
Quantity: 1
Claim Your Seller Account
Mitutoyo 543-311B Bore Gage with Digimatic Indicator
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Mitutoyo 543-311B Bore Gage is a precision instrument designed for accurate bore measurements with a range of 0.5 inches | 12.7 mm and an astounding accuracy of ±.00010 inches | ±.0.003 mm. This gage features an Absolute Electrostatic Capacitance Type Linear Encoder for reliable performance. Equipped with a Digimatic Indicator, it ensures precise readings and comes with a long-lasting CR2032 battery with a life of approximately 12 months. The gage also includes Mitutoyo USB cable and Parameter Setting Software, making it a comprehensive solution for bore gaging applications.
Product Specifications
Accessories 2 Accessories 2
Item # - 905338Item Name - Mitutoyo SPC Connecting Cable (1m)/ 40" - 905338Description - UPC 603908186632 All CALIPERS WITHOUT ABSOLUTE ENCODER Height Gage 570-2XX, 192-6XX, 192-67X Indicators 575-XXX, 543-6XX, 543-2XX, 543-4XX Depth Gages 547-21X, 547-25X, 571-2XX Scale Unit 572-XXX Thickness Gages 547-3XX, 547-4XX
Accessories 3 Accessories 3
Item # - 905409Item Name - Mitutoyo SPC Connecting Cable (2m) - 905410
Technical Specs Accuracy
±.00010 in | ±.0.003 mm
Technical Specs Battery Life
Approximate 12 months under normal use
Technical Specs Battery Type
CR2032 (1 pc.), 05SAA217
Technical Specs Brands
Mitutoyo
Technical Specs Delivery Scope
Item # - 21EZA313Item Name - Mitutoyo USB cable and Outline of Parameter Setting Software - 21EZA314
Technical Specs Ingress Protection Ip Rating
Equivalent to IP-42*1
Technical Specs Maximum Response Speed
Unlimited
Technical Specs Measuring Force
1.5N or less
Technical Specs Model
ID-C112GMXB
Technical Specs Range
0.5 in | 12.7 mm
Technical Specs Standard Length
Absolute Electrostatic Capacitance Type Linear Encoder
