Mitutoyo Dial Bore Gage Set 511-704

Name: Mitutoyo Dial Bore Gage Set 511-704
Brand: Penn Tool Co.
SKU: BOR-e96a84
Price: 399.99 USD
Availability: OutOfStock

SKU:BOR-e96a84

Precision Mitutoyo Bore Gage Set for accurate short-range measurements with self-centering feature and carbide contact points.

$399.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Mitutoyo Dial Bore Gage Set 511-704 is a precision tool designed for short-range applications, offering exceptional accuracy and durability. Featuring a self-centering mechanism with a centring bridge, this gage set minimizes heat influence from the operator’s hand for consistent measurements. It includes interchangeable washers for precise adjustments in small increments and carbide contact points for superior wear resistance. With a measurement range of 100-160mm and an accuracy of 0.00008 in | 2 μm, this gage set is a reliable choice for critical measurements.

Product Specifications

Technical Specs Accuracy

0.00008 in | 2 Î¼m

Technical Specs Brands

Mitutoyo

Technical Specs Digitalanalog

Analog

Technical Specs Graduation

0.0001 in | 0.0005 in | 0.001 mm | 0.01 mm

Technical Specs Indication Stability

1 Î¼m | 0.00004 in

Technical Specs Number Of Anvils

13 in

Technical Specs Number Of Spacers

Technical Specs Range

100 to 160 mm

Technical Specs Stroke Of Contact Point

18 to 60: 1.2 mm | 50 to 400: 1.6 mm

Mitutoyo Dial Bore Gage Set 511-704
