Enhance your precision control systems with Novotechnik's ML10 Series Multi-Turn Rotary Position Sensors. These ultra-compact sensors feature a housing profile of only 13 x 13 mm, offering exceptional linearity, high resolution better than 0.1%, and a mechanical travel of 3600º. With a robust construction including anodized aluminum housing, brass shaft with nickel plating, and sinter bronze sleeve bearings, these sensors ensure reliable performance in demanding environments. The ML10 Series is compliant with federal procurement standards and ideal for government and institutional applications requiring precise position sensing.
Product Specifications
Specifications Actual Electrical Travel
3240 º
Specifications Available Resistance Values
5 kO
Specifications Bearings
Sinter bronze sleeve bearings
Specifications Dielectric Strength Ac 50 Hz 1 Min 1 Bar
750 V
Specifications Dimension A
62.2 mm
Specifications Dimension B
41.7 mm
Specifications Dynamic Permitted Shaft Loading Axial And Radial
1 N
Specifications Electrical Connection
Cable 1 m CRTH 3 x 0.055 mm²
Specifications Housing Material
Anodized Aluminum
Specifications Independent Linearity
0.5 %
Specifications Insulation Resistance 500 Vdc 1 Bar 2 S
= 10,000 MO
Specifications Life
> 15x106 Movements
Specifications Maximum Operational Speed
300 rpm
Specifications Maximum Permissible Applied Voltage
35 V
Specifications Maximum Wiper Current In Case Of Malfunction
5 µA
Specifications Mechanical Travel
3600 º
Specifications Mounting
Nut M10 x 0.75 and serrated washer 3/8”
Specifications Protection Class Din 40050
IP 65
Specifications Recommended Operating Wiper Current
= 1 µA
Specifications Repeatability
0.1 (=3.24º) %
Specifications Resistance Element
Conductive Plastic
Specifications Resistance Tolerance
20 %
Specifications Shaft
Brass | Nickel plated
Specifications Shock Iec 68000 2 27
30 g | 7 ms
Specifications Size
Housing profile 13 x 13 mm
Specifications Special Features
Very small dimensions | 6 - 100 revolutions | Up to 15 x 106 movements | Excellent linearity | High resolution – better than 0.1%
Specifications Static Permitted Shaft Loading Axial And Radial
1 N
Specifications Temperature Range
-25 to 75 º C
Specifications Torque
= 1 N·cm
Specifications Effective Temperature Coefficient Of The
5 ppm/K
Specifications Vibration
30 to 2000 Hz | Amax = 0.75 mm | amax = 10
Specifications Weight
27 g
Specifications Wiper Assembly
Precious Metal multi-finger wiper
