ML100 Series Rotary Position Sensors
ML100 Series Rotary Position Sensors
SKU:MLS-bd101a
High-precision ML100 Series Multi-Turn Rotary Position Sensors by Novotechnik offer exceptional durability and accuracy for various applications. Ideal for industrial and institutional use.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
ML100 Series Rotary Position Sensors
$129.99
Quantity: 1
Claim Your Seller Account
ML100 Series Rotary Position Sensors
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The ML100 Series Multi-Turn Rotary Position Sensors from Novotechnik offer exceptional precision and durability for a wide range of applications. Featuring ultra-compact 13mm housing profiles and available in models with 6 to 100 revolutions, these sensors deliver excellent linearity and high resolution better than 0.1%. With a robust design including anodized aluminum housing, brass shaft with nickel plating, and sinter bronze sleeve bearings, they ensure reliable performance in demanding environments. These sensors are IP65 rated, providing protection against dust and water ingress, making them ideal for industrial and institutional applications. From accurate position sensing to long-lasting performance, the ML100 Series sensors are designed to meet the stringent requirements of government and institutional procurement standards.
Product Specifications
Specifications Actual Electrical Travel
34560 º
Specifications Available Resistance Values
10 kO
Specifications Bearings
Sinter bronze sleeve bearings
Specifications Dielectric Strength Ac 50 Hz 1 Min 1 Bar
750 V
Specifications Dimension A
102.2 mm
Specifications Dimension B
81.7 mm
Specifications Dynamic Permitted Shaft Loading Axial And Radial
1 N
Specifications Electrical Connection
Cable 1 m CRTH 3 x 0.055 mm²
Specifications Housing Material
Anodized Aluminum
Specifications Independent Linearity
0.25 %
Specifications Insulation Resistance 500 Vdc 1 Bar 2 S
= 10,000 MO
Specifications Life
> 15x106 Movements
Specifications Maximum Operational Speed
300 rpm
Specifications Maximum Permissible Applied Voltage
35 V
Specifications Maximum Wiper Current In Case Of Malfunction
5 µA
Specifications Mechanical Travel
36000 º
Specifications Mounting
Nut M10 x 0.75 and serrated washer 3/8”
Specifications Protection Class Din 40050
IP 65
Specifications Recommended Operating Wiper Current
= 1 µA
Specifications Repeatability
0.01 (=3.46º) %
Specifications Resistance Element
Conductive Plastic
Specifications Resistance Tolerance
20 %
Specifications Shaft
Brass | Nickel plated
Specifications Shock Iec 68000 2 27
30 g | 7 ms
Specifications Size
Housing profile 13 x 13 mm
Specifications Special Features
Very small dimensions | 6 - 100 revolutions | Up to 15 x 106 movements | Excellent linearity | High resolution – better than 0.1%
Specifications Static Permitted Shaft Loading Axial And Radial
1 N
Specifications Temperature Range
-25 to 75 º C
Specifications Torque
= 1 N·cm
Specifications Effective Temperature Coefficient Of The
5 ppm/K
Specifications Vibration
30 to 2000 Hz | Amax = 0.75 mm | amax = 10
Specifications Weight
37 g
Specifications Wiper Assembly
Precious Metal multi-finger wiper
