ML6 Series Rotary Position Sensor - Ultra-Compact, High Precision
ML6 Series Rotary Position Sensor - Ultra-Compact, High Precision
SKU:MLS-52ff4f
Ultra-compact ML6 Series Rotary Position Sensors with superior precision and durability for industrial applications.
Regular price
$199.99
Regular price
Sale price
$199.99
Unit price
per
Initiate Order
ML6 Series Rotary Position Sensor - Ultra-Compact, High Precision
$199.99
Quantity: 1
Claim Your Seller Account
ML6 Series Rotary Position Sensor - Ultra-Compact, High Precision
$199.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The ML6 Series Multi-Turn Rotary Position Sensors from Novotechnik offer unparalleled precision and durability for demanding industrial applications. With a compact 13mm profile and a range of 6 to 100 revolutions, these sensors boast excellent linearity and resolution better than 0.1%. Constructed with anodized aluminum housing, brass shaft with nickel plating, and sinter bronze sleeve bearings, they ensure reliable performance even in harsh environments. The ML6 Series meets stringent industry standards, making them ideal for government and institutional procurement needs.
Product Specifications
Specifications Actual Electrical Travel
2160 º
Specifications Available Resistance Values
5 kO
Specifications Bearings
Sinter bronze sleeve bearings
Specifications Dielectric Strength Ac 50 Hz 1 Min 1 Bar
750 V
Specifications Dimension A
62.2 mm
Specifications Dimension B
41.7 mm
Specifications Dynamic Permitted Shaft Loading Axial And Radial
1 N
Specifications Electrical Connection
Cable 1 m CRTH 3 x 0.055 mm²
Specifications Housing Material
Anodized Aluminum
Specifications Independent Linearity
2 %
Specifications Insulation Resistance 500 Vdc 1 Bar 2 S
= 10,000 MO
Specifications Life
> 15x106 Movements
Specifications Maximum Operational Speed
300 rpm
Specifications Maximum Permissible Applied Voltage
42 V
Specifications Maximum Wiper Current In Case Of Malfunction
5 µA
Specifications Mechanical Travel
2160 º
Specifications Mounting
Nut M10 x 0.75 and serrated washer 3/8”
Specifications Protection Class Din 40050
IP 65
Specifications Recommended Operating Wiper Current
= 1 µA
Specifications Repeatability
0.17 (=3.6º) %
Specifications Resistance Element
Conductive Plastic
Specifications Resistance Tolerance
20 %
Specifications Shaft
Brass | Nickel plated
Specifications Shock Iec 68000 2 27
30 g | 7 ms
Specifications Size
Housing profile 13 x 13 mm
Specifications Special Features
Very small dimensions | 6 - 100 revolutions | Up to 15 x 106 movements | Excellent linearity | High resolution – better than 0.1%
Specifications Static Permitted Shaft Loading Axial And Radial
1 N
Specifications Temperature Range
-25 to 75 º C
Specifications Torque
= 1 N·cm
Specifications Effective Temperature Coefficient Of The
5 ppm/K
Specifications Vibration
30 to 2000 Hz | Amax = 0.75 mm | amax = 10
Specifications Weight
27 g
Specifications Wiper Assembly
Precious Metal multi-finger wiper
